Exploring Band Stop Filter Frequency Response: Key Principles & Applications

Series resonant LC band-pass filter

Radar and communications systems can experience signal integrity degradation due to unwanted energy from LO leakage, harmonic distortion, or adjacent band interference. Left unaddressed, these issues may lead to reduced accuracy, impaired situational awareness, or increased vulnerability to interference.

Broad-spectrum filtering reduces some noise, but you need precision when the threat lives in a narrow and high-priority frequency band. Band stop filters deliver that precision by selectively rejecting unwanted signal components while preserving the desired signal with minimal loss. The shape of their frequency response, governed by notch depth, bandwidth, and Q factor, determines whether the solution is merely adequate or truly mission-ready.

This article breaks down the frequency response principles behind band stop filters, the design tradeoffs that define their effectiveness, and how they safeguard aerospace and defense systems against persistent and high-impact interference.

What Is a Band Stop Filter and How Does It Work?

A band stop filter is a two-port network designed to attenuate a defined range of frequencies while allowing signals outside that range to pass with minimal insertion loss. In LC-based analog designs, this is accomplished by connecting a low pass and high pass section in parallel rather than in series, as in a band pass filter. This parallel topology creates a resonant “trap” at the unwanted frequency, effectively removing it from the signal path.

series-resonant-lc-band-pass-filterParallel LC blocks resonant frequency, passes others (Image credit: allaboutcircuits)

Compared to other filter types, a band stop filter functions as the inverse of a band pass filter: rather than isolating a desired frequency range, it suppresses an undesired one.

“A low pass and high pass filter can be connected in parallel to form a wideband notch filter. Just make sure the lowpass cutoff frequency is lower than the high-pass cutoff frequency.”

- Rafid Ali, Applications Engineer, Q Microwave



Understanding Frequency Response Characteristics

A band stop filter’s performance depends on more than blocking an unwanted frequency; it’s defined by key frequency response parameters that balance interference suppression with signal integrity and system efficiency. These parameters include center frequency, bandwidth, quality factor (Q), attenuation depth, insertion loss, and phase behavior.

Center Frequency (𝑓0)

The center (resonant) frequency (𝑓₀) is the midpoint of the rejected band and represents the point where the filter’s attenuation is at its maximum. It is typically calculated using the LC resonant formula:

Where L is the inductance and C is the capacitance. At this frequency, a parallel LC network forms a high impedance “trap”, effectively notching out the unwanted signal while allowing other frequencies to pass with minimal insertion loss. It also serves as the primary reference for tuning the filter to target a specific interference source.

Bandwidth (BW)

Bandwidth (BW) refers to the range of frequencies that the filter attenuates. It can be tailored by adjusting/tuning component values, such as inductance (L) and capacitance (C), or by modifying the filter’s topology, allowing designers to fine-tune the rejection range for specific application requirements.

Quality Factor (Q)

The quality factor (Q) determines the sharpness of the filter’s rejection band. A higher Q factor produces a narrower and more selective notch with steeper roll-off, while a lower Q results in a broader but shallower attenuation profile. This parameter directly impacts how precisely the filter can isolate and suppress unwanted signals without affecting nearby frequencies.



Attenuation Depth

Attenuation depth, usually measured in decibels (dB), indicates how effectively the filter suppresses the target frequency. In high-performance designs, attenuation typically ranges from 30 to 60 dB or more, ensuring that unwanted signals are reduced to levels that no longer impact system operation.

Insertion Loss Outside the Stop Band

Insertion loss outside the stop band should ideally remain below 1 dB to preserve signal strength in the usable frequency spectrum. Excessive insertion loss in the passbands can degrade the signal-to-noise ratio (SNR) and impair overall system performance. Achieving low passband loss requires careful filter topology, high-Q components, and tight manufacturing tolerances.

Phase Behavior and Group Delay

Phase behavior and group delay are most affected near the edges of the stop band and must be carefully managed in phase-sensitive systems. Applications such as beamforming arrays and high-speed digital communication links are particularly vulnerable to phase distortion, making this parameter a critical consideration in filter design and integration.

Why Frequency Response Matters in RF Systems

High-power radar and communications transmitters often generate harmonics, LO leakage, or other spurious emissions that can fall directly into the operating band of nearby receivers or sensitive system components. Left unchecked, these unwanted signals can degrade performance, mask critical returns, or even cause complete signal loss.

Band stop filters are a proven way to selectively attenuate these unwanted frequencies. They can block persistent EMI sources, suppress known jamming signals, and eliminate self-generated emissions that could interfere with other subsystems. This capability is particularly valuable in military environments where adversarial threats are anticipated and every dB of signal clarity counts.

“If a jamming frequency is known, a notch filter can be used to ‘notch’ out the narrow band of jamming frequencies.”

- Rafid Ali, Applications Engineer, Q Microwave

Practical Use Cases

  • Radar Systems – Suppresses known reflections or intermodulation products that could obscure small or distant target returns.
  • Tactical Communication Links – Removes high-intensity interference or harmonics that could otherwise overload sensitive RF front ends.
  • Electronic Warfare & Countermeasures – Prevents internally generated emissions from causing system self-jamming.

By selectively removing certain frequencies, band stop filters can help maintain signal quality, reduce strain on hardware, and support stable operation in demanding RF environments.

Key Design Considerations and Best Practices

Designing an effective band stop filter begins with precise component selection. In LC-based designs, you need precise L and C values to resonate at the undesired frequency, ensuring maximum attenuation. High-Q inductors and capacitors are essential for maintaining a sharp, well-defined filter response.

Thermal and aging stability are also critical. Variations in temperature can shift the center frequency (𝑓₀) and alter the Q factor, potentially reducing rejection performance. For demanding environments, such as space, avionics, or desert operations, filters must be built from materials with tight tolerances and stable electrical properties.

Radiation resistance is another important design parameter in space-qualified systems. Passive LC filters often outperform active designs under radiation exposure, as semiconductors can degrade unless they are specifically radiation-hardened.

Filter placement strategy can make or break system performance. Placing a band stop filter ahead of critical receive stages, such as a low-noise amplifier (LNA) or analog-to-digital converter (ADC), helps prevent overload and preserve signal integrity. In complex systems, these filters are often integrated into multi-stage networks for enhanced roll-off and rejection.

Before deployment, validation tools play a vital role. Simulation platforms, like AWR Microwave Office, help refine the design, while real-world verification with a calibrated Vector Network Analyzer (VNA) confirms performance. Key S-parameters such as S21 (insertion loss) and S11 (return loss) verify both the rejection level and impedance match.

Bridging design and deployment requires understanding not just the filter’s specifications, but also how it interacts with the broader system. This context ensures that lab-verified performance translates into reliable results in the field.

“Customers usually bring specs to us, but we always want to know how our filters fit in the larger system. That helps us fine-tune the design and get the match right.”

- Rafid Ali, Applications Engineer, Q Microwave



Bringing It All Together: Why Frequency Response Matters and What to Do Next



In aerospace and defense systems, where every signal matters, band stop filters reject interference while preserving signal integrity. Understanding key parameters,  such as center frequency, bandwidth, attenuation depth, and insertion loss, helps engineers avoid performance bottlenecks and design filters that meet mission requirements. The next step is applying these principles to your own RF system, ensuring frequency response accuracy and integration practices align with your platform’s operational needs.
